Our Carbon Steel (CS) and Stainless Steel (SS) Flanges, including Anchor Flanges and Long Weld Neck Flanges, are manufactured using premium-grade materials to ensure superior performance in demanding industrial environments. These flanges provide excellent resistance to corrosion, heat, and fire, along with exceptional strength and long-term durability.
Stainless Steel (SS) Flanges are highly hygienic, easy to clean, and ideal for sanitary and critical applications. Carbon Steel (CS) Flanges offer a cost-effective, sustainable, and fully recyclable solution for a wide range of industrial piping systems.
We also supply flanges in a broad range of standards, materials, pressure classes, and custom specifications through our extensive stock and sourcing network, ensuring reliable availability and prompt delivery.
Technical Specifications
| Category | Details |
|---|---|
| Product Type | CS / SS Flanges, Anchor Flanges, Long Weld Neck Flanges |
| Size Range | 1/2” to 48” |
| Wall Thickness | All schedules including SCH 160 and XXS |
| Facing Types | FF (Flat Face), RF (Raised Face), RTJ (Ring Type Joint) |
| Pressure Class | 150, 300, 600, 900, 1500, 2500 |
| API Pressure Rating | API 3000, 5000, 10000 |
| Standards | ANSI B16.5 / B16.47 Series A (MSS SP-44), ANSI B16.47 Series B, API 6A/6BX |
| Material Grades | ASTM/ASME A/SA 105N |
| Material Grades | ASTM/ASME A/SA 350 LF2 CL 1/2 |
| Material Grades | ASTM A694 F52 |
| Material Grades | ASTM/ASME A/SA 516 Gr. 60/65/70 |
| Material Grades | ASTM/ASME A/SA 182 F304/L, F316/L |
| Compliance | NACE MR-0175 |
Key Features
| Feature | Description |
|---|---|
| Corrosion Resistance | Suitable for harsh and corrosive industrial environments |
| Thermal Resistance | Performs reliably under high-temperature operating conditions |
| Durability | High strength, excellent structural integrity, and long service life |
| Hygienic Properties | Stainless Steel flanges are easy to clean, maintain, and sanitize |
| Sustainability | Carbon Steel flanges are recyclable and provide an eco-friendly solution |
| Wide Availability | Extensive stock range with reliable sourcing and prompt delivery options |
